Supports 4-20mA/0-20mA current output (4μA/5μA resolution) and 1-5V/0-5V voltage output (1mV/1.25mV resolution), with factory calibration errors of ±8μA (4-20mA, 25℃) and ±50mV (voltage mode). Power requirements are 20-30VDC (±10% fluctuation), maximum load capacitance 2000pF. Suitable for high-precision counting and frequency/period measurement of pulse signals, such as the GE VMIACC-5595-208 control pulse card module, it can simultaneously process multi-channel pulse signals to meet the precise control needs of industrial automation.

　　Many products are not yet listed. Please contact us for more product information.

　　If the product model differs from the displayed image, the model number shall prevail. Please contact us for specific product images; we will arrange to take photos in our warehouse for confirmation.

　　We have 76 shared warehouses worldwide, so it may sometimes take several hours to return an accurate reply. We apologize for any inconvenience. Of course, we will respond to your inquiries as soon as possible.

　　DS200DTBCG1AAA Other Names:

　　PCB Board DS200DTBCG1AAA

　　DS200DTBCG1AAA Input/Output Board

　　Analog Board DS200DTBCG1AAA

　　The DS200DTBCG1AAA is a high-performance relay terminal board from GE (General Electric), belonging to the core modules in the field of industrial automation, and widely used in PLC systems, process control, and data acquisition scenarios.

　　Technical Specifications

　　Terminal Configuration: Two terminal blocks, each capable of connecting 110 signal lines (some models, such as DS200DTBAG1AAA, support 95 lines), including two 3-pin connectors, one 2-pin connector, and 10 jumpers.

　　Electrical Parameters: Supports 4-20mA/0-20mA current output (4μA/5μA resolution) and 1-5V/0-5V voltage output (1mV/1.25mV resolution), factory calibration error ±8μA (4-20mA, 25℃) and ±50mV (voltage mode). Power supply requirements: 20-30VDC (±10% fluctuation), maximum load capacitance 2000pF.

　　Sampling and Transmission: Single-channel sampling rate 1.25GS/s, time resolution 800ps, supports multi-channel parallel synchronous acquisition; data transmission via Gigabit Ethernet (LXI standard compatible), waveform analysis and data export (MATLAB/ASCII/binary formats, etc.) can be achieved using SBench 6-Pro software.

　　Communication Capabilities: Supports SRTP, EGD, Modbus TCP protocols, LXI standard compatible, integrated Gigabit Ethernet interface and SBench 6-Pro data export function.

　　Physical and Isolation: Approximately 21cm x unspecified dimensions, 0.2kg weight, compatible with PLC racks; features field-to-backplane optical isolation, rack grounding withstand voltage of 250VAC (continuous)/1500VAC (1 minute), ensuring electrical safety in industrial environments.

　　Functional Features

　　Multi-protocol Communication: Supports SRTP, EGD, Modbus TCP protocols, built-in switch reduces hardware costs, provides 4-level password access and audit trail functions to ensure encrypted and traceable data transmission.

　　High-precision control: Suitable for high-precision counting and frequency/period measurement of pulse signals, such as the GE VMIACC-5595-208 control pulse card module, which can simultaneously process multi-channel pulse signals to meet the precise control requirements of industrial automation.

　　Flexible configuration: Supports multiple input/output configurations. Users can dynamically adjust parameters (such as pulse signal processing logic) through programming to adapt to the automation needs of different processes.

　　Installation and maintenance:

　　Replacement steps: First, disconnect all power to the driver (including rectifier DC power and AC power); when removing the old board, record the signal line connection positions and use temporary labels to mark the terminal IDs; when installing the new board, align it with the cabinet holes, wear an anti-static wrist strap, and avoid scratching the circuit board with a screwdriver.

　　Signal management: During installation, move the signal lines to one side to reduce interference with other modules; after replacement, reconnect the signal lines and test the communication function.

　　Cable Management: Terminal blocks typically come with two 3-pin connectors, one 2-pin connector, and ten jumpers. Each terminal block can connect 95-110 signal lines. Care must be taken with cable layout to prevent compression or interference with other components.

　　Application Scenarios

　　Industrial Control: Widely used in automation systems in industries such as power, metallurgy, petroleum, chemical, ports, and wastewater treatment, including DCS (Distributed Control System), CCS (Compressor Control System), and SIS (Safety Instrumented System).

　　Data Acquisition: Supports real-time data acquisition and historical data query (by time/batch number). Combined with curve management, alarm management (storage, statistics, linkage), and electronic signature functions, it enables traceability and safety control of the production process.

　　Equipment Integration: Compatible with equipment from ABB, Siemens, Bentley, and other brands. It can be embedded as a modular component in industrial control systems, improving system reliability and scalability.

　　Environmental Adaptability: Operating temperature range 0-60℃ (some models -40 to 100℃), industrial-grade protection design, strong resistance to electromagnetic interference.

　　In summary, the DS200DTBCG1AAA, with its high precision, multi-protocol capabilities, strong isolation, and flexible configuration, has become a key component in industrial automation, suitable for signal processing and control needs in demanding industrial scenarios. Replacement or maintenance must be performed in strict accordance with operating procedures to ensure stable system operation.

　　All products on this website are special products, and market prices are constantly fluctuating.

　　Please refer to customer service for a specific quote, as the price is not accurate as it is for new products.

　　Please confirm the model, product, price, and other detailed information with customer service before placing an order. This website is currently in use.

　　New products are available for sale; please contact customer service for further information.
